7. Data processing

7.1. Menu data processing

The menu „Data processing" allows the selection
of the following functions:
Select:
This sub-menu enables to search for or
create a plant file for the allocation of
measurement values (see chapter 3.).
Look at:
The recorded values of the selected plant can
be viewed (see chapter 3.).
Load data:
Possibility of data import e.g. from Chimney Sweepers Management
Programmes (check the transfer options of your software and if need
be, adjust them at the instrument / see chapter 6.).
Proceed as follows:
1. Connect instrument and PC with a current RS232 cable.
2. Select "Load data" and confirm with <OK>.
3. Answer following question with Yes (<F1>).
4. Decide if the date recorded in the instrument can be deleted (<F1>
for Yes / <F4> for No).
5. Start the data transfer at the PC.
Transmit data:
The date record completed with values can be transferred to the PC
programme using this function (procedure identical to „Load data").
Format memory:
This function is normally only needed by the initial adjustment of the
instrument by the manufacturer (preparation of internal memory to
data receipt). Caution: All recorded values will get lost !
Page 16
Select
Look at
Load data
Transmit data
Format memory
ecom-CN
