7. After Measurement

After the measurements have been completed, the following things have to be observed
BEFORE turning the instrument off.

7.1 Save measurement, print measurement

Hint
Once the gas analysis is completed and a memory place is chosen before, transfer
the values recorded in the intermediate memory on the MM card, otherwise they
would get lost by switch-off of the instrument!
Hint
The functions „View memory", „Memory -> M" and „Input text" can also be
selected out of the measurement mode with <Enter>.
Page 48
To store measured values permanently on the MM card,
proceed as follows
To access these functions directly via the measurement screen,
press the <Enter> key.
Press <Print> (printer symbol) to enter the printing menu.
The sampled data can be checked one more time („View
memory", <Enter> and scroll with the cursor keys). The
cursor keys can be used to scroll through the
measurement screens.
By selecting the "Insert text" menu item, the plant
identifier can be entered or changed.
See chapter "Measurement procedure gas analysis: Data
processing" for more information.
All data correct? Then press „Memory -> M" and <Enter>
to transfer them in the internal memory or on the MM card
("Symbol memory" is shown in black in the measurement
mode). The inputted text is taken over into the data record
only by transfer on MM card.
Select („Start printout" and <Enter>) to print out the data.
Press <ESC> to turn back to the gas analysis mode.
