Part 6.8: User LEDs

On the AX7010 FPGA development board, two LEDs are connected to the
BANK500 IO in the PS section, and the user can use these two LEDs to debug
the program. When the BANK500 IO voltage is high, the LED light is off, and
when the BANK500 IO voltage is low, the LED will be illuminated. A schematic
diagram of the ZYNQ BANK500 IO and LEDs connections is shown in Figure
6-14:
33 / 48
ZYNQ FPGA Development Board AX7010 User Manual
Signal Name
PMOD_IO0
PMOD_IO2
PMOD_IO3
PMOD_IO4
GND
+3.3V
PMOD_IO1
PMOD_IO6
PMOD_IO7
PMOD_IO5
GND
+3.3V
Figure 6-14: User LEDs Schematic
