SD card slot pin assignment:
Signal Name
SD_CLK
SD_CMD
SD_D0
SD_D1
SD_D2
SD_D3
SD_CD

Part 6.7: PS PMOD connector

The AX7010 development board reserves a 12-pin 2.54mm pitch PMOD
interface (J12) for connecting the IO of the BANK500 and external modules or
circuits. Because the IO is 3.3V standard, the signal of the connected external
devices and circuits also requires a 3.3V level standard. The schematic
diagram of the PMOD connector is shown in Figure 6-12.
Figure 6-13: PS PMOD connector on the FPGA board
32 / 48
ZYNQ FPGA Development Board AX7010 User Manual
ZYNQ Pin Name
PS_MIO40
PS_MIO41
PS_MIO42
PS_MIO43
PS_MIO44
PS_MIO45
PS_MIO47
Figure 6-12: PS PMOD connector Schematic
Amazon Store: https://www.amazon.com/alinx
ZYNQ Pin
Number
D14
C17
E12
A9
F13
B15
B14 SD Card Insertion Signal
Description
SD Clock Signal
SD Command Signal
SD Data0
SD Data1
SD Data2
SD Data3
