Part 6.2: DDR3 DRAM

The AX7010 FPGA development board is equipped with two
DDR3
chips
MT41J128M16HA-125
533MHz (data rate 1066Mbps), and two DDR3 memory systems are directly
connected to the memory interface of the BANK 502 of the ZYNQ Processing
System (PS). The specific configuration of DDR3 SDRAM is shown in Table
6-2.
Bit Number
U8,U9
The hardware design of DDR3 requires strict consideration of signal
integrity. We have fully considered the matching resistor/terminal resistance,
trace impedance control, and trace length control in circuit design and PCB
design to ensure high-speed and stable operation of DDR3.
