Chapter 4

Connecting Frequency Measurement Signals

One way to measure frequency is to connect a pulse of a known duration (such as a one-shot
output of another user counter) to the external gate input, as shown in
configuration, the frequency of the clock input is the number of counts divided by the period
of the external gate input.
Signal Source
Figure 16: Connecting Frequency Measurement Applications to the DT740 Screw Terminal Panel
54
User Clock Input 0
Digital Ground
Digital Shield
(Shown for Clock Input 0 and External Gate 0)
Figure
DT740 Panel
TB58
Gate 0
TB60
TB61
TB63
Counter
TB83
Output 1
TB108
16. In this
User
