Chapter 4
Connecting Analog Output Signals
Figure 10
panel.
50
shows how to connect analog output voltage signals to the DT740 screw terminal
Analog Output 0
Load
Analog Output 0
Figure 10: Connecting Analog Output Voltages to the DT740
(Shown for Channel 0)
DT740 Panel
TB41
TB42
Return
Analog Shield
TB51
