Chapter 6

External Digital (TTL) Trigger

For analog input operations, an external digital trigger event occurs when the DT3034 board
detects either a rising or falling edge on the External A/D TTL Trigger input signal connected
to screw terminal 77 on the DT740 screw terminal panel. The trigger signal is TTL-compatible.
Using software, specify the trigger source as an external, positive digital (TTL) trigger for a
rising-edge digital trigger (OL_TRG_EXTERN for DataAcq SDK users) or an external,
negative digital (TTL) trigger for a falling-edge digital trigger (OL_TRG_EXTRA for DataAcq
SDK users).
Analog Threshold Trigger
For analog input operations, an analog trigger event occurs when the DT3034 detects a
transition from above a threshold level to below a threshold level (falling edge), or a transition
from below a threshold level to above a threshold level (rising edge). The following analog
threshold trigger sources are available:
• External Analog Trigger input signal – This trigger source is supported by the DataAcq
• One of the analog input channels after gain is applied (also called the output of the
On DT3034 boards, the threshold level is set using a dedicated 8-bit DAC (the second D/A
subsystem). The hysteresis is fixed at 50 mV. Using software, program the threshold level by
writing a voltage value to this DAC; this value can range from –10 V to +10 V.
Note: If you are using an analog threshold trigger to trigger both the A/D and the D/A
subsystems, ensure that you use the same analog trigger type for both subsystems (either
external or one of the analog input channels). The polarity of the triggers, however, can be
different.
80
SDK; it is not supported by the DT-Open Layers Class Library.
Connect an external analog trigger signal to screw terminal 107 on the DT740 screw
terminal panel.
Using software, specify the trigger source as either a rising-edge (OL_TRG_EXTRA+1 for
DataAcq SDK users) or falling-edge analog threshold trigger (OL_TRG_EXTRA+2 for
DataAcq SDK users).
programmable gain amplifier (PGA). Using software, specify the trigger source as either a
positive threshold trigger or negative threshold trigger.
Using software, specify the analog input channel used as the analog threshold trigger as
the first channel in the channel list; refer to page 72 for more information.
