Appendix A

Connector Specifications

Table 28
50-Pin Connector
Plug for cable:
Cable shell kit:
Cable wire:
Receptacle for board:
Latching posts:
68-Pin Connector
Plug for cable:
Cable shell kit:
Cable wire:
Receptacle for board:
Latching posts:
EP307
EP308
150
lists the connector specifications for the DT3034 boards and corresponding cables.
Table 28: Connector Specifications for the DT3034 Board
Feature Specifications
AMP/Tyco 5787131-1
AMP/Tyco 787133-1
AMP/Tyco 57506-1
AMP/Tyco 6658751-1
AMP/Tyco 787003-3 (bag of 200)
AMP/Tyco 5787131-3
AMP/Tyco 787229-1
AMP/Tyco 57508-1
Molex 71430-0101
AMP/Tyco 787003-3 (bag of 200)
Amp/Tyco 1-636326-1
Amp/Tyco 1-636327-1
