2. Connect Analog Out Return to Analog In 3 Return.
Analog Output 1+ Return
Analog Input 3 Return
Follow the instructions on
Configuring for an External Meter
To calibrate DAC0 using an external voltage meter, do the following:
1. Connect Analog Out 0+ to the positive side of the precision voltage meter.
Analog Output 0+
2. Connect Analog Out 0 Return to the negative side of the precision voltage meter.
Analog Output 0 Return
To calibrate DAC1 using an external voltage meter, do the following:
1. Connect Analog Out 1+ to the positive side of the precision voltage meter.
2. Connect Analog Out 1 Return (TB44) to the negative side of the precision voltage meter.
Analog Output 1+ Return
Signal DT740 Screw Terminal
page 132.
Signal DT740 Screw Terminal
Signal DT740 Screw Terminal
Signal DT740 Screw Terminal
Analog Output 1+
Signal DT740 Screw Terminal
TB44
TB8
TB41
TB42
TB43
TB44
Calibration
131
