Measurement Computing Data Translation DT3034 User Manual page 157

Appendix B
Connector J2 on the DT3034 Board
Table 31
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
156
lists the pin assignments of connector J2 on the DT3034 boards.
Table 31: Connector J2 Pin Assignments on the DT3034 Board
Signal Description
+ 5 V Output
Reserved
A/D Trigger Output
External A/D Sample Clock Input
External D/A Clock Input
User Clock Input 3
User Clock Input 2
User Clock Input 1
User Clock Input 0
Digital I/O Bank B 3
Digital I/O Bank B 1
Digital Ground
Digital I/O Bank A 2
Digital I/O Bank A 0
Dynamic Digital Output 1
Reserved
Shield Ground
Digital Ground
Reserved
Digital Ground
Digital Ground
Digital Ground
Digital Ground
Digital Ground
Digital Ground
Digital Ground
Digital I/O Bank B 7
Digital I/O Bank B 5
Digital Ground
Pin Signal Description
2 + 5 V Output
4 A/D Sample Clock Output
6 External A/D TTL Trigger
8 External D/A TTL Trigger
10 User Counter Output 3
12 User Counter Output 2
14 User Counter Output 1
16 User Counter Output 0
18 Digital Ground
20 Digital I/O Bank B 2
22 Digital I/O Bank B 0
24 Digital I/O Bank A 3
26 Digital I/O Bank A 1
28 Digital Ground
30 Dynamic Digital Output 0
32 Reserved
34 Analog Trigger
36 Digital Ground
38 Digital Ground
40 Digital Ground
42 Digital Ground
44 External Gate 3
46 External Gate 2
48 External Gate 1
50 External Gate 0
52 Digital Ground
54 Digital I/O Bank B 6
56 Digital I/O Bank B 4
58 Digital I/O Bank A 7
