1. EU EcoDesign Disclosures
EcoDesign Disclosures
1.4 Ultrastar Data102 Disassembly
Step 59 : Use a T7 Torx screwdriver to remove the eleven (11) M3 6mm screws securing the smaller, front
baseboard to the chassis. The screws are shown in red in the following image:
46
