1. EU EcoDesign Disclosures
EcoDesign Disclosures
1.4 Ultrastar Data102 Disassembly
Removing the PDB from the IOM Housing
Step 40 : Lay the IOM housing on its side.
Step 41 : Use a T7 Torx screwdriver to remove the eighteen (18) M3 6mm screws securing the right side-
panel of the IOM housing:
30
