Step 28 : Uninstall the Cable Tray by removing the M3 x 8mm screws using the long T10 Torx head
screwdriver.
Figure 25: Uninstalling the Cable Tray
Removing the Chassis Cover from the Enclosure
Step 29 : Slide the chassis cover toward the rear of the enclosure. Then lift it up to remove it from the
chassis:
1. EU EcoDesign Disclosures
1.4 Ultrastar Data102 Disassembly
