1. EU EcoDesign Disclosures
EcoDesign Disclosures
1.4 Ultrastar Data102 Disassembly
Figure 40: IOM Housing Location
Step 39 : Use a T7 Torx screwdriver to remove the fourteen (14) M3 6mm screws securing the IOM housing
to the drive housings. Then pull the IOM housing upward to remove it from the chassis:
29
