5-4
Figure 5-1: Press and hold Ready button (1) and then Press Power switch (2)
4

Printer test card

The printer test card is designed to perform most of the functions available in the
printer.
Release the Ready button. You hear the internal components initialize. Allow 30 to
60 seconds for the printer to begin printing the test card. The status light will flash
green while the Select printer is processing the data.
A printer test card is shown in Figure 5-2 on page 5-4.
If the printer test card did not print successfully, see "Status light" on page 2-7.
Red
Green
Dark Blue
Black
Figure 5-2: ImageCard printer test card (using color ribbon)
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
2
1
Black Border
Troubleshooting
Blue Cyan
Magenta
Yellow
Black
