PC settings for Windows Me and 98

This section describes the following for PCs running Windows Me and 98.
•
•
User's Guide for the ImageCard® IV Printer
Figure C-4: Communications Port Properties dialog box
Choose the Port Settings tab.
i
If the PC has more than one serial port, make sure you view the settings for
the serial port to which the smart card module is attached.
Choose the following settings:
Setting Value
Baud rate 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
When the settings are correct, click OK to save settings and close the dialog box.
Setting parallel port values
Setting serial port values
♦
C-7
