Alinx AX7050 User Manual page 45

Figure 3-9-1: Expansion header J8 schematic
Figure 3-9-2: Expansion header J8 on the Carrier Board
J8 Expansion Header Pin Assignment
Pin Number
1
3
5
7
9
11
13
15
17
19
21
23
45 / 52
Spartan-7 FPGA Development Board AX7050 User Manual
FPGA Pin
GND
T20
V20
Y21
R18
R16
T17
U18
V18
V21
V22
T21
Amazon Store: https://www.amazon.com/alinx
Pin Number
2
4
6
8
10
12
14
16
18
20
22
24
FPGA Pin
+5V
T19
U20
W21
R17
N15
R17
U17
U19
V19
W22
U22
