PIN67 B14_L18_N
PIN69 B14_L18_P
PIN71 B14_L17_N
PIN73 B14_L17_P
PIN75 GND
PIN77 TDI
PIN79 TMS
The pins of B15_L14_P/N, B15_L16_P/N, B15_L5_P/N, B15_L13_P/N,
B15_L6_P/N and B15_L4_P/N are differentially derived on the PCB and can be
used as high-speed LVDS data communication.
Figure 2-9-2: Board to Board Connectors CON1 on the Core Board

Part 2.10: Power Supply

The AC7050 FPGA core board is powered by DC5V via Carrier Board, and
it is powered by the Mini USB interface when it is used alone. Please be careful
not to supply power to the Mini USB and the Carrier Board at the same time to
avoid damage. The power supply design diagram on the board is shown in
Figure 2-10-1.
27 / 52
Spartan-7 FPGA Development Board AX7050 User Manual
T20
T19
R20
R19
- Ground
W9
Y10
Amazon Store: https://www.amazon.com/alinx
I/O PIN68 B15_L6_P
I/O PIN70
N.C. PIN72 B15_L4_N
N.C. PIN74 B15_L4_P
PIN76
O PIN78
O PIN80
K15
GND -
G16
H16
GND -
TCK G9
TDO W10
I/O
Ground
I/O
I/O
Ground
O
I
