Parameters
Trigger Cache Enable
Trigger Debouncer
× means that specific trigger parameters are not supported, and √ means that specific trigger
parameters are supported.

8.6.1 Set Trigger Activation

The camera supports trigger acquisition in the rising edge and falling of the external signal. The
principle and parameter of trigger activation are shown below.
Trigger Activation
Rising Edge
Falling Edge
Click Acquisition Control > Trigger Activation, and select Trigger Activation according to actual
demands.
USB3.0 Board Level Camera
Sources Software Trigger
Table 8-4 Trigger Activation Principle and Parameter
Parameter
Acquisition Control >
Trigger Activation
Acquisition Control >
Trigger Activation
User Manual
·
Hardware Trigger
√
×
Parameter Value
Rising Edge
Falling Edge
24
Counter Trigger
√
√
Principle
Rising Edge refers to the rising
edge of the trigger signal is
valid, that is camera exposure
and acquisition at the
beginning of the rising edge of
the trigger signal.
Falling Edge refers to the falling
edge of the trigger signal is
valid, that is camera exposure
and acquisition at the
beginning of the falling edge of
the trigger signal.
√
×
