RS232 P A
IN SSIGNMENT
The AccuPyc is a standard DTE device. The RS232 port can be used to connect an analytical
balance for transfer of sample weight, or for transmitting data to a computer. The receiving device
must be configured to interface with the RS232 pin assignments. Any signals that are not listed in the
RS232 Pin Assignment table are ignored.
RS232 Pin Assignments
Signal
Pins
RXD Receive Data
2
TXD Transmit Data
3
DTR Data Terminal Ready
4
GND Ground
5
DSR Data Set Ready
6
The AccuPyc uses the DTR and DSR signals for hardware flow control. Ensure that the serial
device provides these signals. For example, if attaching to a computer (also a DTE device), use a
null modem cable which includes the designated signals. If transmission problems occur, ensure that
the signals are set up properly. If the signals are correctly configured, contact the receiving device
manufacturer for assistance.
11 - 6
Description Data Direction
Into AccuPyc
From AccuPyc
From AccuPyc
Into AccuPyc
N/A
AccuPyc II 1345 Operator Manual
134-42851-01 (Rev A) — Jan 2021
