GENERAL
To aid in the understanding and troubleshooting of an
electrical system, review the terms and information that
follows.
CAUTION
K no w t he el e ct r i ca l ci r c ui t be fo r e c on ne ct in g or
disconnecting an electrical component. A wrong
connection can cause personal injury or damage to the
component and/or system.
Electrical Energy - power which comes from the movement
of electrons. Electrons are particles with a negative charge.
Electrons will collect around particles with a positive charge,
called protons, until an electrical imbalance occurs.
Amperage - rate of flow of electrons (CURRENT), measured
in amperes.
Voltage - the electromotive force (EMF) which causes
electrons to move through an electrical circuit, measured in
volts.
