CD3340B/YB4411
SECTION CONTENTS
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Environmental Protection . . . . . . . . . . . . . . . . . . . 5-1
Lubricants and Capacities . . . . . . . . . . . . . . . . . . . 5-1
Maintenance Records . . . . . . . . . . . . . . . . . . . . . . 5-2
After First 50 Hours of Operation (New Cranes). . 5-3
Cranes not in Regular Use . . . . . . . . . . . . . . . . . . 5-3
Preventive Maintenance. . . . . . . . . . . . . . . . . . . . . 5-3
Maintenance Schedule and Checklist. . . . . . . . . . 5-3
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Lubrication Points . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Grease Fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Scheduled Maintenance. . . . . . . . . . . . . . . . . . . . 5-13
Daily (Walk-around) . . . . . . . . . . . . . . . . . . . . . . 5-13
INTRODUCTION
General
Preventive maintenance at regular intervals is necessary to
keep your machine in good condition as long as possible.
Adjust the maintenance schedule to your operation,
according to type of work, size of loads, temperature
conditions and frequency of machine use.
The intervals in the Maintenance Schedule are average
operating conditions and must be understood as the
MINIMUM maintenance necessary for the machine. Shorten
these intervals if the machine is operated in conditions that
are below average (for example - in dust, in high or low
temperatures, with heavy loads or frequent starting and
stopping).
Use the hour meter to make sure that all necessary
maintenance is done according to schedule.
ENVIRONMENTAL PROTECTION
Dispose of waste properly! Improperly disposing of waste
can threaten the environment.
GROVE
SECTION 5
MAINTENANCE
50 Hours of Operation/Weekly. . . . . . . . . . . . . . . 5-17
100 Hours of Operation . . . . . . . . . . . . . . . . . . . . 5-19
250 Hours of operation/Monthly. . . . . . . . . . . . . . 5-20
500 Hours Of Operation/Three Months . . . . . . . . 5-26
1000 Hours of Operation/Six Months. . . . . . . . . . 5-29
Replace the Hoist Gearbox Lubricant
(Braden Model) . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
2000 Hours Of Operation/Yearly . . . . . . . . . . . . . 5-35
Miscellaneous Maintenance . . . . . . . . . . . . . . . . 5-36
Carwell® Rust Inhibitor. . . . . . . . . . . . . . . . . . . . . 5-38
Protecting Cranes From Rusting . . . . . . . . . . . . . 5-38
Cleaning Procedures . . . . . . . . . . . . . . . . . . . . . . 5-38
Inspection and Repair . . . . . . . . . . . . . . . . . . . . . 5-39
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-39
Areas of Application. . . . . . . . . . . . . . . . . . . . . . . 5-39
Potentially harmful waste used in Manitowoc cranes includes
- but is not limited to - oil, fuel, grease, coolant, air
conditioning refrigerant, filters, batteries, and cloths which
have come into contact with these environmentally harmful
substances.
Handle and dispose of waste according to local, state, and
federal environmental regulations.
When filling and draining crane components, observe the
following:
• Do not pour waste fluids onto the ground, down any
drain, or into any source of water.
• Always drain waste fluids into leak proof containers that
are clearly marked with what they contain.
• Always fill or add fluids with a funnel or a filling pump.
• Immediately clean up any spills.
LUBRICANTS AND CAPACITIES
It is not the policy of Manitowoc, Inc. to publish lists of
approved lubricants or to guarantee lubricant performance.
The responsibility for the quality of a lubricant rests
Published 04/07/2015 Control # 569-00
MAINTENANCE
5
5-1
