Manitowoc Grove CD3340B Service Manual page 113

CD3340B/YB4411
p0307
Both Sides
Lift Cylinder Lube Points
p0308
Steering Knuckle Lube Points
(Rear Axle)
p0308
Steering Cylinder Pivot Lube
Points- Rod End (Rear Axle)
GROVE
FIGURE 5-7
Both Sides
FIGURE 5-8
Both Sides
FIGURE 5-9
Published 04/07/2015 Control # 569-00
Steering Cylinder Pivot Lube
p0309
Points - Base End (Rear Axle)
Steering Link Pivot Lube Points
Both Sides
p0310
p0311
Steering Knuckle Lube
Points (Front Axle)
MAINTENANCE
FIGURE 5-10
(Rear Axle)
FIGURE 5-11
FIGURE 5-12
5-11
5
