Manitowoc Grove CD3340B Service Manual page 110

MAINTENANCE
No Location Name
Rear Steer Axle
7 Hub Bearings
8 Kingpin Bearings
9 Steer Linkage Bearing
10 Steering Cylinder
Engine & Trans.
11 Engine Crankcase
12 Engine Coolant
13 Transmission
Turntable
14 T/T Gear Box
15 T/T Gear & Pinion
16 T/T Bearing
Cylinders
17 O/R Cylinder
18 Lift Cylinder
Boom
19 Boom Nose Sheaves
20 Jib Boom Sheave
21 Boom Sections
22 Tele Cylinder Wear Pads
23 Boom Extension Sheave
24 Boom Ret Sheave
25 Hook Block Swivel Bearing
26 Boom Pivot Shaft
27 Hook Block Sheaves
Outriggers
28 Slide Box
29 Jack Tube
Hoist
30 Hoist Gearbox
31 Hoist Brake
32 Cable Follower
Misc.
33 Driveline Joints
34 Fuel Tank
35 Hydraulic, Oil Tank
Notes:
5-8
5.8-7.4 Qts (5.5-7.0 L)
3.7 Gal (13.9 Liters)
4.5 Gal (17.0 Liters)
1.0 Qts (0.95 Liters)
0.25 Qts (0.24 Liters)
17.0 Gal (64.4 Liters)
34.5 Gal (130.6 Liters)
1. All pintle hooks, etc. shall be oiled or greased as required.
Published 04/07/2015 Control # 569-00
Capacity Symbol
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EO-15W-40
AFC
HTF
EP-MPG
EP-OGL
EP-MPG
ASC
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EP-MPG
EPGL-5
Transynd
EP-MPG
EP-MPG
HYDO
CD3340B/YB4411
Instruction
See Note 4
See Notes 2 & 10
See Note 6
See Note 6
See Note 9
See Note 7
See Note 8
See Notes 4 & 5
