TRANSMISSION AND TORQUE CONVERTER
Converter Pressures (in neutral):
Converter IN at 122°F (50°C)
1000 rpm
2000 rpm.
Converter OUT at 122°F (50°C)
1000 rpm
2000 rpm
Converter Inlet Relief Valve Pressure (Max.)
Lubrication Pressures (in neutral)
At 122°F (50°C)
1000 rpm
2000 rpm
Mainline Pressure (in neutral)
At 122°F (50°C)
1000 rpm
2000 rpm
Flow Rates (in neutral)
Cooler at 122°F (50°C)
1000 rpm
2000 rpm
Pump at 122°F (50°C)
1000 rpm
2000 rpm
The following clutch pressures should be the same as the Mainline Pressure to within 10 PSI (0.7 bar):
Input Clutch Pressure (high and low ratio)
Reverse Clutch Pressure (high and low ratio)
Layshaft Clutch Pressure
Mainshaft Clutch Pressure
Clutch Solenoid Technical Data
Type
Operating Flow
Operating Pressure
Leakage (maximum)
Coil Operating Voltage
Pull-in Voltage
Dropout Voltage
Peak Voltage
Coil Resistance
7-2
PSI............................Bar
40-60......................2.8-4.1
70-90.......................4.8-6.2
PSI...........................Bar
27-33......................1.9-2.3
33-39.......................2.3 - 2.7
95............................6.5
PSI..........................Bar
2.0-4.0....................0.14-0.28
4.0-8.0.................... 0.28-0.55
PSI...........................Bar
130-145...................9.0 - 10.0
140-160....................9.7-11.0
GPM................................LPM
2.8-3.6.........................10.4-13.6
3.8-5.3..........................14.5-20.0
2.9-4.0........................11.0-15.0
6.0-7.8..........................22.5-29.5
4-way, 3-position, directional control
9.85 gpm (40 L/min)
145 psi (10 bar)
50 cc/min @ 40°C, 10 bar
(14 in/min.@104°F,145psi)
+12V DC nominal (9V-16V)
+10.5V (max.) @ 25°C (77°F) air
+ 1.5V (min.) at 20°C (68°F) air
+ 26V DC for 5 minutes at 0°C (32°F)
4.9 ohms ± 5% @ 20°C (68°F)
