Section 1 - Manitowoc Grove RT600E Operator's Manual

RT600E OPERATOR MANUAL
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
List Of Specifications . . . . . . . . . . . . . . . . . . . . . . . 1-2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Torque Converter . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Axles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Brakes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Wheels And Tires . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Swing Gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
This handbook has been compiled to assist you in properly
operating and maintaining your Grove Crane.
Before placing the crane in service, take time to thoroughly
familiarize yourself with the contents of this manual. After all
sections have been read and understood, retain the manual
for future reference in a readily accessible location.
The Grove Crane has been designed for maximum
performance with minimum maintenance. With proper care,
years of trouble-free service can be expected.
Constant improvement and engineering progress makes it
necessary that we reserve the right to make specification
and equipment changes without notice.
Grove and our Distributor Network want to ensure your
satisfaction with our products and customer support. Your
l o c a l d i s t r i b u t o r i s t h e b e s t e q u i p p e d a n d m o s t
knowledgeable to assist you for parts, service and warranty
issues. They have the facilities, parts, factory trained
personnel, and the information to assist you in a timely
manner. We request that you first contact them for
assistance. If you feel you need factory assistance, please
ask the distributor's service management to coordinate the
contact on your behalf.
Engine operating procedures and routine maintenance
procedures are supplied in a separate manual with each
crane, and should be referred to for detailed information.
Information in this manual does not replace federal, state, or
local regulations, safety codes, or insurance requirements.
GROVE

SECTION 1

INTRODUCTION
Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Swivel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Hydraulic Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Hoists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Noise/vibration Test Results . . . . . . . . . . . . . . . . . 1-3
Noise Level Test Results . . . . . . . . . . . . . . . . . . . . 1-3
Vibration Level Test Results . . . . . . . . . . . . . . . . . 1-3
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Supplemental Information . . . . . . . . . . . . . . . . . . . 1-4
New Owners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Serial Number Location Figure 1-2 . . . . . . . . . . . . 1-5
GENERAL
NOTE:
NOTE:
This Operator Manual provides important information for the
operator of the Model RT600E Series Grove Crane.
The rough terrain crane incorporates an all welded steel
frame, using planetary drive axles to provide four-wheel
drive. Axle steering is accomplished utilizing hydraulic steer
cylinders. The engine is mounted at the rear of the crane and
provides motive power through a six speed forward and
three speed reverse transmission. Hydraulic, double box,
sliding beam outriggers are integral with the frame.
The carrier frame incorporates an integral fifth wheel, to
which the rear axle is mounted, to provide axle oscillation.
Axle oscillation lockout is automatic when the superstructure
rotates from the travel position.
The superstructure is capable of 360° rotation in either
direction. All crane functions are controlled from the fully-
enclosed cab mounted on the superstructure. The crane is
equipped with a four-section, cable-synchronized boom.
Additional reach is obtained by utilizing an optional
swingaway boom extension. Lifting is provided by a main
hoist and an optional auxiliary hoist.
Published 05-02-2018 Control # 088-10
Throughout this handbook, reference is made to
left, front, and rear when describing locations.
These reference locations are to be considered as
those viewed from the operator's seat with the
superstructure facing forward over the front of the
carrier frame.
Basic crane nomenclature is shown in Figure 1-2.
INTRODUCTION
1
1-1
