CD3340B/YB4411
2. A mixture of 50% AFC and 50% water is required for all
standard units.
3. All moveable control links and clevis pins shall be
lubricated with ASC.
4. Final fluid levels shall be adjusted by use of dip sticks,
markings or filler plugs.
5. The hydraulic oil shall meet or exceed manitowoc
cleanliness spec. 6829014631.

Grease Fittings

Apply grease to the following fittings after every 50 hours of operation. Use a Lithium Base, E.P. No. 2 bearing grease or
equivalent. Apply enough grease to remove the old grease.
NO LOCATION
1 Mast Bearing (SeeFigure 5-2)
2 Boom Pivot (See Figure 5-3)
3 Retract Chain Roller - 2nd Boom Section (See Figure 5-4)
4 Boom Head Sheaves and Pivot (See Figure 5-5)
5 Extend Chain Roller Assembly (See Figure 5-6)
6 Lift Cylinder Pivots (See Figure 5-7
NO LOCATION
7 Steering Knuckles - Rear Axle (See Figure 5-8)
8 Steering Cylinder Pivot Ends - Rear Axle (See Figure 5-9 and Figure 5-10)
9 Steering Link Pivot Ends - Rear Axle (SeeFigure 5-11)
10 Steering Knuckles - Front Axle - (See Figure 5-12)
11 Drive Shaft (See Figure 5-13)
12 Parking Brake (See Figure 5-14)
NO LOCATION
13 Drop Block (See Figure 5-15)
14 Jib Boom Head Sheave (See Figure 5-16)
15 Jib Boom Deflector Sheave (See Figure 5-17)
GROVE
6. Apply to pins prior to assembly.
7. Both sides.
8. All sides.
9. Lubricate all surfaces in contact with wear pads.
10. Engine coolant capacity listed is the combined capacity
for coolant in the engine and radiator.
BOOM AND MAIN FRAME
DRIVE TRAIN
OPTIONAL EQUIPMENT AND ACCESSORIES
Published 04/07/2015 Control # 569-00
MAINTENANCE
QTY
2
2
2
2
2
5
2
QTY
2
2
2
4
3
1
QTY
1
1
1
5-9
