Basic Controls

Table 4-2 describes basic controls which helps in checking the LOGIQ™ 100 PRO during
installation.
Connect the sector or convex transducer to connector on the right side of the base.
Turn `ON' Power Switch
Press New Patient Key
Press ID/Name
Press Dyn Range Up/Down
Rotate Gain Knob
Press Reverse
Press Reverse a second time
Press SHIFT + Reverse
Press SHIFT+ Reverse a second
time
Press M key
Roll Trackball
Press M key a second time
Press Freeze key
Press ATO
Press Freeze and Zoom
Roll Trackball
Table 4-2 Basic Controls
Page 4-6
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 8 1 o f 1 9 7
3
EVISION
TASK
Section 4-1 - Overview
LOGIQ™ 100 PRO S
Expected Result
B-Mode screen as in figure 4-3should appear
A pop-up window appears. Enter Patient Name/ID. It
presets the system
A pop-up window appears. Enter Patient Name/ID. It
does not preset the system.
Image grows softer and harder depending on position.
Image grows lighter and darker with rotation.
The image will be displayed Left/Right
The image will be displayed Right/Left.
The image will be displayed Top/Bottom
The image will be displayed Bottom/Top
B/M Mode with M-line cursor appears. (Use trackball to
move the M-line cursor). Refer Figure 4-4
The M-Line cursor should follow the trackball movement
and the real-time image varies on the M-Mode display.
Only M-Mode image appears on the screen.
Press B Mode Key to exit M-Mode.
The image will freeze.
ATO, Automatic Tissue Optimization, optimizes the
image based upon a specified Region Of Interest (ROI)
or anatomy within the display. ATO Gray scale map is
available only in B-Mode.
Zoom is used to magnify an image. The magnification
factor for zoom is fixed at 2.0. The system adjusts all
imaging parameters accordingly.
To select the ROI for Zoom
Zoom feature is avialable in the freezed mode only.
