3-5-5 Adjustment of Monitor Brightness & Contrast
Turn ON the Machine and then adjust the monitor contrast and brightness. Monitor contrast and
brightness should be adjusted according to the lighting in the room. For Monitor brightness and
contrast adjustment refer to the appropriate section in the User Manual.
3-5-6 Adjustment of System Clock/Date, Hospital Name & OB Version
Press CTRL-S-1 ENTER, an `Installation Setup window appears'. Set the system Clock/Date,
Hospital Name and OB Version. These settings can be modified by using the CONTROL-S-1 key if
required. Refer Section Control Keys of the User Manual for more details
CAUTION Functional checks in Chapter 4, to be carried out before handing over the system to the
customer

Section 3-6 System Configuration

3-6-1

System Specifications

3-6-1-1

Physical Dimensions

The physical dimensions of the LOGIQ™ 100 PRO unit are summarized in Table 3-2.
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 6 2 o f 1 9 7
3
EVISION
Height
28.9
Table 3-3 Physical Dimensions of LOGIQ™ 100 PRO
Chapter 3 - Installation
LOGIQ™ 100 PRO S
Width Depth
30.24 42.06
M
ERVICE ANUAL
Unit
cm
Page 3-17
