4-2-1-4

Front Panel ON/OFF

Press the Front Panel ON/OFF key once. to Switch ON/OFF
Figure 4-2 ON/OFF key on Front Panel
When power is applied to the Scanner, Power is distributed to the Fan, Control panel, Monitor,
Internal and External I/O's, Boards & Peripherals. Back End Processor starts and its software code
is distributed to initiate the scanner.
Power Up Display Comes Up. Refer figure 4-3.
4-2-1-5

Power Shutdown

1.) Switch OFF the ON/OFF at the Front of the system.
2.) Disconnect the Mains Power Cable if needed.
