Chapter 7 Diagnostics/Troubleshooting

Section 7-1Overview

7-1-1

Purpose of Chapter 7

This section describes how to setup and run the tools and software that help maintain image quality
and system operation. Very basic host, system and board level diagnostics are run whenever power
is applied. Some Service Tools may be run at the application level.
The LOGIQ™ 100 PRO System service diagnostics comprises of:
1.) Self test or power on diagnostics
2.) Service diagnostic tools
The self test or power on diagnostics are run every time the system is booted. The service
diagnostic tools include test procedures for testing the system at PCB level as well as block level.
The diagnostic tools provides a pop-up menu to enable selection of various tests to test various
blocks on the system.
CONTENTS IN CHAPTER 7
Table 7-1 Contents in Chapter 7
