Section 8-5 PCBs

8-5-1 Disassembly/Assembly of Davinci Board.
Follow steps below and refer
1.) Remove Top Cover. Refer 8-2. For FRU Details refer 9-1-7 to
9-1-9
2.) For disassembling both Davinci Board and FEB Board together, remove all communications
and power cables from the Davinci board and FEB board.
3.) Remove two screws to detach the PCB Assembly from the chassis.
4.) Pull the Davinci and FEB boards upward.
5.) For Davinci Board only, remove four screws (four from the Davinci board) and detach the
Davinci board separately from the flush connector on the FEB.
6.) For assembly follow the reverse order.
Table 8-7 Functional tests
Service Manual
Page 8-14
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 1 4 3 o f 1 9 7
3
EVISION
Section Functional Test/ Diagnostic Test
4-2-1
4-2-1 Power OFF/ Shut down
4-3
4-5 Software configuration check
7-2
Section 8-5 - PCBs
Power ON/ Boot up
Functional Checks
Diagnostics tests
LOGIQ™ 100 PRO S
ERVICE
Debrief Script
Service manual direction
5305880-100, Section 8-5-
1.Equipment passed all required
tests and is ready for use.
