Chapter 10 Quality Assurance; Section 10-1 Overview; Purpose Of Chapter 10 - GE LOGIQ 100 PRO Technical Publication

G HE
E ALTHCARE
D 5305880-100, R
IRECTION

Chapter 10 Quality Assurance

Section 10-1 Overview

10-1-1

Purpose of Chapter 10

This chapter describes Quality Assurance & Periodic Maintenance (PM) on the scanner and its
peripherals. These PM procedures are intended to maintain the quality of the ultrasound systems
performance. Read this chapter completely and familiarize yourself with the procedures before
starting a PM.
CONTENTS IN CHAPTER 10
Table 10-1 Contents in Chapter 10
Practice good ESD prevention. Wear an anti–static strap when handling electronic parts and
even when disconnecting/connecting cables.
THERE ARE SEVERAL PLACES ON THE REAR PANEL THAT ARE
DANGEROUS. BE SURE TO DISCONNECT THE SYSTEM POWER PLUG AND
OPEN THE MAIN CIRCUIT BREAKER BEFORE YOU REMOVE ANY PARTS. BE
CAUTIOUS WHENEVER POWER IS STILL ON AND COVERS ARE REMOVED.
Do not pull out or insert circuit boards while power is ON.
Do not operate this unit unless all board covers and frame panels are securely in place. System
performance and cooling require this.
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 1 7 2 o f 1 9 7
3
EVISION
Section
10-1
Overview
10-2
Why do Periodic Maintenance
10-3
Periodic Maintenance Schedule
10-4
Tools Required
10-5
System Periodic Maintenance
10-6
Electrical Safety Tests
10-7
When There's Too Much Leakage Current...
PM Inspection Certificate
Chapter 10 - Quality Assurance
LOGIQ™ 100 PRO S
Description
M
ERVICE ANUAL
Page Number
10-1
10-2
10-2
10-4
10-7
10-11
10-23
10-29
Page 10-1
