Chapter 1 Introduction

Section 1-1Overview

1-1-1

Overview

The LOGIQ™ 100 PRO is a compact portable ultrasound scanner which is designed for OB/GYN,
Abdomen, Urology and small part Scans using the convex, linear and micro-convex (Transvaginal)
probes. High quality images can be obtained by the proper selection of scan control parameters.
The diagnostic clarity is further enhanced by the different measurement and calculation packages
available in the system.
1-1-2

Purpose of Chapter 1

This chapter describes important issues related to safely servicing this ultrasound machine. The
service provider must read and understand all the information presented here before installing or
servicing a unit.
CONTENTS IN CHAPTER 1
Table 1-1 Contents in Chapter 1
1-1-3

Purpose of Service Manual

This Service Manual provides installation and service information for the LOGIQ™ 100 PRO
Ultrasound Scanning System and contains the following chapters:
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 1 8 o f 1 9 7
3
EVISION
Section Description
1-1 Overview
1-3 Important Conventions
1-4 Safety Considerations
1-5 EMC, EMI, and ESD
1-6 Customer Assistance
1.) Chapter 1, Introduction: Contains a content summary and warnings.
2.) Chapter 2, Pre-Installation: Contains any pre-installation requirements for the
LOGIQ™ 100 PRO.
3.) Chapter 3, Installation: Contains installation procedure with installation checklist.
4.) Chapter 4, Functional Checks: Contains functional checks that must be performed as
part of the installation, or as required during servicing and periodic maintenance.
5.) Chapter 5, Theory: Contains block diagrams and functional explanations of the
electronics.
6.) Chapter 6, Service Adjustments: Contains instructions on how to make any available
adjustments to the LOGIQ™ 100 PRO.
7.) Chapter 7, Diagnostics/Troubleshooting: Provides procedures for running and
diagnostic or related routines for the LOGIQ™ 100 PRO.
8.) Chapter 8, Replacement Procedures: Provides disassembly procedures and
reassembly procedures for all changeable FRU.
Chapter 1 - Introduction
LOGIQ™ 100 PRO S
ERVICE
Page Number
M
ANUAL
1-1
1-4
1-9
1-18
1-20
Page 1-1
