Section 8-10 Chassis

8-10-1

Disassembly/Assembly of Chassis.

Follow steps below and refer 8-16
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. For assembly follow the reverse order.
Table 8-13 Functional tests
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 1 5 4 o f 1 9 7
3
EVISION
Remove Top Cover. Refer 8-2. For FRU Details refer 9-1-12
Remove Front Panel. Refer 8-4-1
Remove Monitor Assembly. Refer 8-4-2
Remove PCBs. Refer 8-5
Remove the fan. Refer 8-6.
Remove the rear panel. Refer 8-8
Remove Power Supply. Refer 8-7-1
Remove HV Power Supply. Refer 8-9
Remove the chassis by removing eight screws (a,b,c,d,e,f,g,h) on the base.
Service Manual
Section Functional Test/ Diagnostic Test
4-2-1
4-2-1
4-3
7-2
4-5 Software Configuration checks
4-6
Chapter 8 - Replacement Procedures
Power ON/ Boot up
Power OFF/ Shut down
Functional Checks
Diagnostics tests
Peripheral checks
LOGIQ™ 100 PRO S
ERVICE
Debrief Script
Service manual direction 5305880-
100, Section 8-10-1.Equipment
passed all required tests and is ready
for use.
