GE LOGIQ 100 PRO Technical Publication page 68

GE H
EALTHCARE
D 5305880-100, R
IRECTION
3.6.4.2 Video Graphic Printer (VGP)
Connect the Video Graphic printer (with USB A to USB B cable) to the USB port located on the rear
panel of the system.
Model: (Sony UP-D897MD or UP-897MD)
Figure 3-20 Connection of USB cable to Printer
Installation of VGP:
1.) Place the SONY Digital Printer on the fixture.
2.) Fix one end of power cable and USB cable to the printer.
3.) Fix the other end of USB cable to the USB slot provided in the rear panel and power cable
4.) Switch ON the LOGIQ™ 100 PRO and VGP printer.
5.) Press the Recall button on the keyboard to view the stored images.
6.) Press Record button on the keyboard and check if the selected image matches with the
3.6.4.3 Pin Assignment of Mini Jack controlling VGP
Figure 3-21 Shutter Connector
3.6.4.4 Video Casette Recorder
Connect the VCR Sony SVO-9500MD (H4120SR) for NTSC and Sony SVO 9500MDP(E11801AA)
for PAL System to the Video IN socket in the rear panel. Press the "EXT. VIDEO" button on the
keyboard to enable an external video signal on the system monitor. SVHS tape should be used for
recording.
Page 3-24
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 6 9 o f 1 9 7
3
EVISION
to the Power socket.
VGP print out.
Pin No.
1
2
Section 3-6 - System Configuration
LOGIQ™ 100 PRO S
Signal
Shutter
Signal GND
M
ERVICE ANUAL
