GE H
EALTHCARE
D
5305880-100, R
IRECTION
9-1-10
MATERIAL LIST - Rear Panel
5304117,5304414,5304240,5304248,5304441,5304596,5306834.
Figure 9-9 Rear Panel Assembly
Table 9-9
Item
Part Name
901
Rear panel Assembly
902
FAN Assembly
Page 9-12
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 1 6 7 o f 1 9 7
3
EVISION
OPERATOR CONSOLE ASSY
901
Rear Panel Assy
Part No.
5305191
2139798
Section 9-1 - Overview
LOGIQ™ 100 PRO S
Description
LOGIQ™ 100 PRO
LOGIQ™ 100 PRO
902
M
ERVICE
ANUAL
Qty
1
1
