Chapter 6 Service Adjustments

Section 6-1 Overview

6-1-1 Service Adjustments Available in LOGIQ™ 100 PRO
The LOGIQ™ 100 PRO does not contain service adjustable parts. In case of failure of any module
like the Power Supply, HV pcb it is recommended to replace the power supply unit instead of trying
to adjust the potentiometer or replacing the fuse.
No Service Adjustments.
WARNING
DO NOT ADJUST CRT POTENTIOMETERS.
WARNING
Whenever Upgrade of LOGIQ™ 100 PRO is done at field, Please ensure patient data back up is
done before upgrading the machine.
