2. INSTALLATION AND BEFORE START OF
OPERATION OF THE FLOW TRANSMITTER
Install the flowmeter according to the following procedure.
Section 3.2 Installation of flow transmitter
Section 3.3 Flow transmitter wiring
Power ON
Section 4.4 Parameter protection
Checking and Setting of Piping
Section 4.6
Specifications/Detector
OK
Section 5 Mounting of detector
Section 6.5.1.3 Checking the RAS information
OK
Displaying the data in
Section 6.5.2
maintenance mode
Check the data display
AGC U
AGC D
P/H U
P/H D
Section 4.7 Zero Adjustment
Basic operation
Section 4.8 Setting of unit
Section 4.9.1.1 Setting of flow rate range (single
range)
Section 4.9.1.2 Setting of analog output at error
(Burnout)
Application operation
Section 4.9.1 Setting of flow rate range
Section 4.10.1 Setting automatic 2 ranges
Section 4.10.2 Setting the Bi-directional range
Section 4.10.3 Setting the Bi-directional auto 2
range
Section 7.3 ORDERING INFORMATION
Run (Measurement)
Section 6 CHECK AND MAINTENANCE
Note) Set the parameter protection to OFF before you change settings or perform zero adjustment.

2.1. Outline of installation procedure

When A or B is selected for the
12th digit
(LED display is green)
45% or more
5528 to 6758
* Check the power supply specifications and wiring before
turning on the power. (Refer to "1.2.Check on type and
specifications".)
* Metric system is selected for unit.
* The initial display language is English. Switch the languages
as required.
NG When Y or C is selected for the 12th digit
Section 4.6.2
* Be careful not to mount the sensor units with wrong mounting
dimension. Mount it with the dimension displayed at the
process setting of the piping parameter. (Refer to "5.
Mounting of detector".)
NG (LED display is red)
Section 6.5.2
Section 6.5.6
Contact Fuji Electric's service representative.
* Before performing zero point adjustment, check that the pipe
is filled with fluid, the fluid is in still state, and that the
measurement status is normal.
Section 4.9.1.3 Output limit
Section 4.9.2 Setting thee
Section 4.9.3 Setting the DO output
Section 4.9.3.1 How to validate the total pulse
output
Section 4.9.4 Setting the LCD indication
Section 4.10.5.2 How to validate the alarm
output
Section 4.10.5.3 Setting the flow switch
Section 4.10.5.4 How to validate the total
switch
-5-
Piping parameter setting method
Displaying the data in
maintenance mode
Check the data display
AGC U
45% or more
AGC D
P/H U
Outside the range
P/H D of 5528 to 6758
Checking received waveforms
* Check A, B for
the 12th digit of
code symbol
only.
