1.3.2. Flow transmitter : FSV···H (IP67)
(9)
(1)
No.
(1) Wiring connection port
(2) Wiring connection port
(3) Indication and setting unit
Received wave diagnostic
(4)
indication (LED)
(5) Escape key
(6) UP key
(7) Shift key
(8) Entry key
(9) LCD display
(10) Power terminal
(11) Input/output terminal
(12) Communication board terminal
(13) Fuse holder
(14) Communication board
(2) (4)
Name Key
ESC
ENT
(3)
(5) (6) (7) (8)
Wiring connection port for power cable and output cable.
Wiring connection port for signal cable only.
Indicates and sets the flow rate, etc.
Indicates whether received wave is normal (green) or abnormal
(red).
Returns to the next-higher menu level or cancels the set status.
Selects items, numeric values and symbols.
Moves the cursor and selects decimal place.
Enters a selection or registers a setting.
Indicates the flow rate or setting.
Connects the power cable.
Connects signal cable, analog output or DO output cable.
Connects communication cable.
(A communication board is optional)
Fuse holder
Mounted if communication is optionally designated.
-4-
(12)
(10) (13)
Description
(14)
(11)
