Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
Description
Max. reccomended
DC power input
Nominal DC power
input
Nominal input
voltage
Max. absolute input
voltage
Input voltage,
MPPT operating
range
Input voltage,
MPPT operating
range at full power
Max. short circuit
current (of each
array)
Max. operating
input current (of
each array)
Input backfeed
current
Max. input power
(of each channel)
PV Ground fault
protection
Value
PVI–3-0-OUTD
3500 W
3120 W
360 Vdc
600 Vdc
from 90 Vdc to
580 Vdc
from 200 Vdc to
530 Vdc
12.5 Adc
10 Adc
Negligible
2000 W
Ground fault detector and interruption provided
Value
PVI–3.6-OUTD
4150 W
3750 W
360 Vdc
600 Vdc
from 90 Vdc to
580 Vdc
from 200 Vdc to
530 Vdc @Vgrid
= 277 Vac or 240
Vac ;
from 220 Vdc to
530 Vdc @Vgrid
= 208 Vac
20 Adc
16 Adc
Negligible
3000 W
Page 93 of 108
Value
PVI–4.2-OUTD
4820 W
4380 W
360 Vdc
600 Vdc
from 90 Vdc to
580 Vdc
from 200 Vdc to
530 Vdc @Vgrid
= 277 Vac or 240
Vac ;
from 220 Vdc to
530 Vdc @Vgrid
= 208 Vac
20 Adc
16 Adc
Negligible
3000 W
