5.2.2

Internally logged data

Aurora stores internally the following data:
•
Lifetime counter of grid connection time
•
Lifetime counter of energy transferred to the grid
•
Energy transferred to the grid every 10 seconds for the last 8640 periods of 10
seconds (which on average cover more than 2 days logged data)
•
Partial counter of grid connection time (counter start time can be reset using the
Aurora Communicator software)
•
Partial counter of energy (uses the same start time as the partial time counter)
•
Last 100 fault conditions with error code and time stamp
•
Last 100 changes to grid connection parameters with parameter code and new
value.
The first two types of data are displayed on the LCD and through the RS-485
interface, while all other data can be displayed only through the RS-485 interface.
