Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
3.5

CR2032 Lithium Battery Replacement

WARNING: Before performing the following instructions, ALWAYS
perform the "AURORA ELECTRICAL DISCONNECT PROCEDURE"
described in section 3.4.1 of this manual.
Inside the Aurora inverter there is a CR2032 lithium battery. When this battery is at
end-of-life, a message will be shown in the display informing that the battery needs to
be replaced.
The battery is visible after removing the Aurora inverter's front panel. Refer to section
3.3.2 for the procedures to remove the front panel.
To insert the new battery into the battery holder the battery needs to be slid at a 30°
angle as shown in Fig 16, and when pushed in on insertion it should seat into the
correct position within the holder.
WARNING: The replacement of this battery should be performed only by
trained personnel.
After battery replacement is completed, reinstall and secure the front panel of the
inverter and perform the START-UP procedure in section 4.
Fig.16 - Lithium Battery Replacement
Page 48 of 108
