Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
3.1.1

Inspecting package contents

Aurora Inverter
Bag containing:
Nr.4 6.3x70 screws, nr.4 SX10 wall plugs, red cable
AWG10, black cable AWG10, Torx20 wrench, nr.1
6x10 screw, nr.1 d.18 washer,
Installation and Operator's Manual
Certificate of warranty
CD-ROM with communication software
3.2

Selecting the installation location

Installation location should be selected based on the following considerations:
•
Height from ground level should be such as to ensure that the display and status
LEDs are easy to read.
•
Select a well-ventilated location sheltered from direct sun radiation. Choose a
location that allows unobstructed airflow around the inverter.
•
Allow sufficient room around the inverter to enable easy installation and removal
from the mounting surface.
•
A door is provided on the front of the inverter to allow for hardware maintenance;
and the USB port for software connection is on right side wall of the inverter
(protected by a cover). Ensure free access to the right side; otherwise you will
have to remove the inverter from its mounting surface.
The following figure shows the recommended minimum clearances around the
inverter:
Description
Page 19 of 108
Quantity (No.)
1
1
1
1
1
