Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
:
When using an RS-485 link there can be up to 248 inverters connected
NOTE
on the same link. Choose any address between 2 and 248.
:
When using the RS-485 link, in case one or more inverters are added
NOTE
later to the system, please remember to switch the DIP-switch of the former
last inverter of the system back to the OFF position
Fig. 25 - Daisy Chain Multiple Connection
Page 86 of 108
