Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
current
Max. output
current
Output over
current protection
8.3

Grid protection characteristics

Anti islanding protection
8.4

General characteristics

Description
Maximum
efficiency
Internal
consumption
during stand-by
Internal
consumption
during nighttime
Operating ambient
temperature
Casing protection
rating
Audible noise
with internal fan
on
Size (height x
width x depth):
Arms
12/14.5/14.5
Arms
15/20/20 Arms
Value
PVI–3-0-OUTD
96.8% (96 )
EURO
< 8 W
< 2 W
-25°C to +60°C
(*)
IP65 / Nema 4X
< 50 dbA @ 1m
787 x 325 x
208mm
Arms
16/17.2/17.2
Arms
20/25/25 Arms
Complies with:
- UL 1741 standard.
Value
PVI–3.6-OUTD
96.8% (96 )
EURO
< 8 W
< 2 W
-25°C to +60°C
(*)
IP65 / Nema 4X
< 50 dbA @ 1m
787 x 325 x
208mm
Page 95 of 108
Arms
20/20/20 Arms
25/25/25 Arms
Value
PVI–4.2-OUTD
96.8% (96 )
EURO
< 8 W
< 2 W
-25°C to +60°C
(*)
IP65 / Nema 4X
< 50 dbA @ 1m
787 x 325 x
208mm
