First Phase - Electric Parameter Check - Power One AURORA PVI-OUTD-US Series Installation And Operator's Manual

Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
5.5.3

First phase - electric parameter check

A FEW POINTERS ON DISPLAY KEY OPERATION:
During normal operation, the display will cycle through available data. The display
changes to a different screen every 5 seconds, or screens may be scrolled manually by
pressing the UP (2nd key from display) and DOWN keys (3rd key from display).
Either way, pressing the ESC key (right next to the display) calls back the previous
menu.
Auto-scroll is indicated by 2 arrows in the top left corner of the display (see Fig.20).
To stop auto-scroll, press the
appear (see Fig.21).
1A) If the measurements taken previously (see section 5.5.1) are found to be correct,
the system will proceed to the next checks. The 12 screens outlined below are shown
alternately as listed in this section.
2A) shows inverter serial number and firmware revision level.
3A)
E-tod: Daily energy output.
$-tod: Daily energy savings. Value is expressed in the set currency.
Fig.20 Fig.21
ENTER
key (4th key from display). A padlock will
Type OUTD
PN------------
S/N--------- xxxxxx
FW rel. C.0.1.1
E-tod 0 Wh
$-tod 0.0 $
