Installation and Operator's Manual
(PVI-3.0/3.6/4.2-OUTD-x-US Rev: 2.1)
4A)
E-tot: Lifetime energy output (since first installation)
E-par Partial energy output (during selected period)
:
5A)
P-out: Measured instant output power
The second line of the display shows the higher of two temperatures:
T-inv: inverter heat sink temperature or
T-boost: Heat sink temperature
6A)
Ppk: Maximum peak power achieved since partial counter was activated
Ppk Day: Maximum peak power achieved during the day. Counter will reset when unit
is powered off.
7A)
Vgrid: Measured instant grid voltage
Vgrid Avg: Average grid voltage during the last 10 minutes of operation
8A)
Igrid: Measured instant grid current
Fgrid: Measured instant grid frequency
9A)
Vin1: Instant input voltage measured at channel 1 input
Iin1: Instant input current measured at channel 1 input
E-tot -------------
E-par 0 KWh
P-out 0 W
T-inv - °C
Ppk W
Ppk Day ...........W
Vgrid 197 V
Vgrid Avg 0 V
Igrid 0.8 A
Fgrid 50.18 Hz
Vin1 0 V
I in1 0.0 A
Page 65 of 108
