Aurora Universal Installation Guide
Power‐One Aurora Inverters
This installation document covers all details for installing the Aurora Universal System hardware to
work directly with the Power-One Aurora inverter(s). The Fat Spaniel Technologies (FST)
Management System within the Aurora Universal System collects and analyzes energy generation
and usage data for your Aurora inverter(s). Once the hardware is installed, you will need to login to
the FST Partner Portal website to verify the internet is connected properly and verify that the data in
being received.
